£389.00 Inc VAT

Compact passive 12″ speaker
EVS-12K woofer
1.5-inch DH-1K titanium HF compression driver
55 Hz to 20 kHz frequency range
90 x 50 degree coverage-pattern waveguide
60 deg Monitor Angle
94 dB SPL sensitivity; 132 dB max SPL
Power handling: 250 W continuous, 1000 W peak
Braced 15mm plywood enclosure
Pole mount or stack with Live X Subwoofers
Black textured finish

EV
Category: SKU: SP/LOW/EV31

Clear, powerful, and musical, the Live X series was born to command the stage for professional music performance.

Available in both powered and passive versions, Live X loudspeakers offer top-quality components in remarkably affordable configurations that put the EV-quality experience within reach for artists, engineers, and live-sound businesses. Designed for a wide range of portable sound applications, Live X loudspeakers are housed in hardy stackable enclosures of solid wood, making them lighter than comparable-quality composite or plastic boxes and therefore easier to load, transport, and set up. With high output, extended frequency range, and high sensitivity, Live X loudspeakers are clean, flat, and hot, making music of all kinds sound its best. The Live X series is serious gear for serious sound.

Compact power for sound reinforcement and stage monitoring
EVS-12K woofer
1.5-inch DH-1K titanium HF compression driver
55 Hz to 20 kHz frequency range
90 x 50 deg coverage-pattern waveguide
60 deg Monitor Angle
94 dB SPL sensitivity; 132 dB max SPL
Power handling: 250 W continuous, 1000 W peak
Braced 15mm plywood enclosure
Pole mount or stack with Live X Subwoofers
Black textured finish



Axial Sensitivity 94 dB
Case Material 9-ply, 15mm Plywood, Internally Braced, with Texured Paint
Frequency Response (-3 dB) 82 – 18000 Hz
Frequency Response (-10 dB) 55 – 20000 Hz
Internal Crossover Yes
Recommended High-Pass Frequency 45 Hz
Max. SPL/1m (calc); half space 132 dB
Coverage (Nominal -6 dB) H 90
Coverage (Nominal -6 dB) V 50
System Power Handling (Continuous/Program/Peak) 250, n/a, 1000 Watts
LF Transducer (1) EVS-12K, 305mm (12″) Woofer
HF Transducer DH-1K, 39mm (1.5″) Titanium Diaphragm Compression Driver
Crossover Frequency 21000 Hz
Nominal Impedance (Passive) 8 O
Minimum Impedance 7 O
Connector Type Parallel Neutrik’ NL4
Grill 18GA Steel with Black Powdercoat
Height 607 mm (23.9″)
Width 362 mm (14.25″)
Depth 340 mm (13.39″)
Weight Net 20 kg (44.09 lbs)

Brand

Electro-Voice

EV
