£559.00 Inc VAT

15″ passive full range speaker

  • EVS-15K woofer
  • 1.5-inch DH-1K titanium HF compression driver
  • 50 Hz to 20 kHz frequency range
  • 90 x 50 degree coverage-pattern waveguide
  • 60 deg Monitor Angle
  • 95 dB SPL sensitivity; 134 dB max SPL
  • Power handling: 400 W continuous, 1600 W peak
EV
Category: SKU: SP/LOW/EV32

Clear, powerful, and musical, the Live X series was born to command the stage for professional music performance. Available in both powered and passive versions, Live X loudspeakers offer top-quality components in remarkably affordable configurations that put the EV-quality experience within reach for artists, engineers, and live-sound businesses.
Designed for a wide range of portable sound applications, Live X loudspeakers are housed in hardy stackable enclosures of solid wood, making them lighter than comparable-quality composite or plastic boxes and therefore easier to load, transport, and set up. With high output, extended frequency range, and high sensitivity, Live X loudspeakers are clean, flat, and hot, making music of all kinds sound its best. The Live X series is serious gear for serious sound.

  • More power, fuller sound for larger rooms
  • EVS-15K woofer
  • 1.5-inch DH-1K titanium HF compression driver
  • 50 Hz to 20 kHz frequency range
  • 90 x 50 degree coverage-pattern waveguide
  • 60 deg Monitor Angle
  • 95 dB SPL sensitivity; 134 dB max SPL
  • Power handling: 400 W continuous, 1600 W peak
  • Braced 15mm plywood enclosure
  • Pole mount or stack with Live X Subwoofers
  • Black textured finish





Axial Sensitivity 95 dB
Case Material 9-ply, 15mm Plywood, Internally Braced, with Texured Paint
Frequency Response (-3 dB) 75 – 18000 Hz
Frequency Response (-10 dB) 50 – 20000 Hz
Internal Crossover Yes
Recommended High-Pass Frequency 40 Hz
Max. SPL/1m (calc); half space 134 dB
Coverage (Nominal -6 dB) H 90°
Coverage (Nominal -6 dB) V 50°
System Power Handling (Continuous/Program/Peak) 400, n/a, 1600 Watts
LF Transducer (1) EVS-15K, 381mm (15″) Woofer
HF Transducer DH-1K, 39mm (1.5″) Titanium Diaphragm Compression Driver
Crossover Frequency 17000 Hz
Nominal Impedance (Passive) 8 Ohm
Minimum Impedance 7.4 Ohm
Connector Type Parallel Neutrik’ NL4
Grill 18GA Steel with Black Powdercoat

Height 708 mm (27.87″)
Width 432 mm (17.01″)
Depth 382 mm (15.04″)
Weight Net 27.8 kg (61.29 lbs)

Brand

Electro-Voice

EV
