£845.00 Inc VAT
  • Dual 15-inch two-way full-range passive loudspeaker
  • High-volume punch and ultra-wide frequency response
  • Ideal for mains
  • Two EVS-15K woofers for extended LF
  • 1.5-inch DH-1K titanium HF compression driver
  • 38 Hz to 20 kHz frequency range
  • 90 x 50 degree coverage-pattern waveguide
  • 96 dB SPL sensitivity; 137 dB max SPL
  • Power handling: 600 W continuous, 2400 W peak
  • Braced 15mm plywood enclosure
  • Black textured finish
EV
Category: SKU: SP/LOW/EV33

Clear, powerful, and musical, the Live X series was born to command the stage for professional music performance. Available in both powered and passive versions, Live X loudspeakers offer top-quality components in remarkably affordable configurations that put the EV-quality experience within reach for artists, engineers, and live-sound businesses. Designed for a wide range of portable sound applications, Live X loudspeakers are housed in hardy stackable enclosures of solid wood, making them lighter than comparable-quality composite or plastic boxes and therefore easier to load, transport, and set up. With high output, extended frequency range, and high sensitivity, Live X loudspeakers are clean, flat, and hot, making music of all kinds sound its best. The Live X series is serious gear for serious sound.

High-volume punch and ultra-wide frequency response
Ideal for mains
Two EVS-15K woofers for extended LF
1.5-inch DH-1K titanium HF compression driver
38 Hz ¤ 20 kHz frequency range
90 x 50 coverage-pattern waveguide
96 dB SPL sensitivity; 137 dB max SPL
Power handling: 600 W continuous, 2400 W peak
Braced 15mm plywood enclosure
Black textured finish Dual 15-inch two-way full-range loudspeaker

Axial Sensitivity 96 dB
Case Material 9-ply, 15mm Plywood, Internally Braced, with Texured Paint
Frequency Response (-3 dB) 62 Hz – 18 k Hz
Frequency Response (-10 dB) 38 Hz – 20 k Hz
Recommended High-Pass Frequency 35 Hz
Max. SPL/1m (calc) 137 dB
Coverage (Nominal -6 dB) H 90°
Coverage (Nominal -6 dB) V 50°
LF Transducer (2) EVS-15K, 381mm (15″) Woofers
HF Transducer DH-1K, 39mm (1.5″) Titanium Diaphragm Compression Driver
Crossover Frequency 1.7 k Hz
Nominal Impedance (Passive) 4 O
Minimum Impedance 3.7 O
Connector Type Dual NL4
Grill 18GA Steel with Black Powdercoat

Height 1154 mm (45.43″)
Width 432 mm (17.01″)
Depth 501 mm (19.72″)
Weight Net 44.1 kg (97.22 lbs)
Shipping Weight 52 kg (114.64 lbs)
