£675.00 Inc VAT

Compact powered 8″ speaker / monitor
800W integrated amp
90×50 degree dispersion, rotatable horn
Selectable high-pass filter for use with subwoofers
Line and microphone inputs
Built-in pole mount
Lightweight (< 20 lbs)
integral handle for easy carrying

EV

Categories: , , SKU: SP/POW/EV02

Electro-Voice engineers have raised the bar for portable sound once again, adding to the award-winning ZX loudspeaker family with the new ZXA1, the self-powered version of the best-selling ZX1 compact two-way loudspeaker. Launching globally at Winter NAMM 2010, ZXA1 is powered by an 800 watt amplifier module derived from EV’s world-tour-class Tour Grade series amplifiers with audio quality and reliability proven at the very highest levels.

Features
* Designed for Club Sound, Concert Sound, House of Worship, and other applications.
* Integrated 800 watt power amplifier
* Biamplified design with transducer protection
* EV8L 8Œ high-output LF transducer
* DH2005 1Œ exit true compression driver
* 90 x 50 coverage pattern
* Rotatable horn design
* 123 dB maximum SPL
* Selectable high-pass filter for use with subwoofers
* Line and microphone inputs
* Integral monitor angle on enclosure
* Built-in pole mount
* Lightweight (< 20 lbs) with integral handle for easy carrying

Specifications
Input Connections XLR and TRS Combo; XLR with Independent Gain
Power Requirement 120V: 95V – 132V, 50 – 60 Hz, 0.6A; 230V:190V – 264V, 50 – 60 Hz, 0.4A
Frequency Response (-3 dB) 60 Hz – 20 kHz Hz Full Range Mode
Frequency Response (-10 dB) 48 Hz – 20 kHz Hz Full Range Mode
Recommended High-Pass Frequency 100 Hz User Selectable
Max. SPL/1m (calc) 123 dB
LF Transducer EV8L, 203mm (8 in) Driver
HF Transducer DH2005, 25mm (1 in) Exit Compression Driver
Crossover Frequency 1800 Hz
Enclosure Material High Impact Polystyrene
Grill Polyester Powder Coated, 18GA Galvanized Steel
Height 457 mm (17.99″)
Width 282 mm (11.1″)
Depth 264 mm (10.39″)
Weight Net 8.62 kg (19 lbs)
Shipping Weight 10.3 kg (22.7 lbs)

Brand

Electro-Voice

EV
