ART 708-A MK5 is a unique product in its category. The 1.4″ compression driver offers unique vocal clarity and sound projection. The 8” woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalisation, phase control, soft limiting and speaker protections.
Powerful Class D Amplifiers
RCF’s Class-D power amplifier technology packs huge performance operating with high efficiency into a lightweight solution. ART 7 amplifiers deliver ultra-fast attack, realistic transient response and impressive audio performance. The amplifier features a solid mechanical aluminium structure which not only stabilises the amplifier during transportation but also helps the fan-less heat dissipation. All the ART 7 amplifiers present SMPS power supply section in order to produce maximum output and minimum transportation weight.
Superior Transducers
Woofers and compression drivers are precision built taking advantage of RCF’s technologies and a wealth of professional knowledge and experience dedicated to achieving extremely high standards.
Your Ideal Stage Partner
The ART 7 speakers are the perfect choice for musicians and sound provider alike. Their cabinets are molded from a proprietary polypropylene composite engineered to quell vibrations, even at the highest volume levels. This translates to exceptional reliability and resilience under rigorous stage conditions.
Acoustical specifications
Frequency Response | 60 Hz ÷ 20000 Hz
Max SPL @ 1m| 128 dB
Horizontal coverage angle | 90°
Vertical coverage angle | 70°
Transducers
Compression Driver | 1 x 1.0”, 1.4” v.c
Woofer | 1 x 8”, 2.0” v.c
Input/Output section
Input signal | bal/unbal
Input connectors | XLR, Jack
Output connectors | XLR
Input sensitivity | -2 dBu/+4 dBu
Mic. Input Sensitivity | -32 dBu
Processor section
Crossover Frequencies | 1600
Protections | Thermal, RMS
Limiter | Soft Limiter
Controls | Volume, Boost, MIC/Line
Power section
Total Power | 1400 W Peak
High frequencies | 400 W Peak
Low frequencies | 1000 W Peak
Cooling | Convection
Connections | VDE
Physical specifications
Cabinet/Case Material | PP Composite
Hardware | 2 x M10
Handles | 1 on top
Pole mount/Cap | 35 mm insert
Grille | Steel
Color | Black
Size / Weight
Height | 480 mm / 18.9 inches
Width | 291 mm / 11.46 inches
Depth | 276 mm / 10.87 inches
Weight | 10.4 kg / 22.93 lbs
