Hand held Condenser ‘ Roaming’ Radio Mic only
Replaces previous version WM5220
For use with TOA 5000 series radio mic Systems (with WM5200, WM5800 etc)
Ideal as alternative mic to use on TOA lapel systems.
Available in channel 70 (no licence required) and Channel 38 (licence required)
DM Music recommends all radio mics are used on licenced frequencies (channel 38 or Fixed Site Licences). From 2013 Channel 70 (unlicenced) may experience interference from 4G Mobile phone networks. Please also see our DM Quick Expert Guide for more information. We can also arrange licences on your behalf. Please call us on 01582 761122 for more information.
Hand held Condenser ‘ Roaming’ Radio Mic only
Replaces previous version WM5220
For use with TOA 5000 series radio mic Systems (with WM5200, WM5800 etc)
Ideal as alternative mic to use on TOA lapel systems.
Available in channel 70 (no licence required) and Channel 38 (licence required)
Although Lapel mic systems are very popular for worship leaders for sermons and talks there are times when the congregation need to be heard. By simply using the TOA WM5225 ‘roaming’ condenser radio mic (instead of you current lapel mic) church members can pass this mic around to help contribute to the service.
Available in channel 70 (no licence required) and Channel 38 (licence required) – please select
This mic is ideal for all users, even those less experienced or who find using microphones uncomfortable – the condenser mic element can pick up speech and singing wether held close to the mouth or at arms length.
THIS PRODUCT IS THE HAND HELD MIC ONLY AND DOES NOT INCLUDE THE TOA RADIO RECEIVER (Use this mic instead of lapel microphone) – for complete TOA 5000 radio mic systems please see our Radio Mics section.
Microphone Element | Electret condenser microphone unit: Unidirectional |
---|---|
Modulation | Frequency modulation |
Frequency Range | G01 = 606 – 614 MHz* or D04 = 863 – 865 MHz UHF (options only for Chan 38 or Chan 70) |
Channel Selectable | 64 channels (the number of channels may differ from country to country) |
RF Carrier Power | 50 mW or less |
Tone Frequency | 32.768 kHz |
Oscillator | PLL synthesized |
Maximum Input Level | 126 dB SPL |
Maximum Deviation | ±40 kHz |
Audio Frequency Response | 100 Hz – 15 kHz |
Dynamic Range | 95 dB or more (with WT-5800) |
Battery | WB-2000 (WB-2000-2 contains 2 pieces) rechargeable battery (option) or AA alkaline dry cell battery |
Battery Life | Approx. 13 h (when the WB-2000 rechargeable battery is used) Approx. 10 h (when the alkaline battery is used) |
Indicator | Power/Battery lamps |
Antenna | Built-in type |
Operating Temperature | -10 ℃ to 50 ℃ (14 ゜F to 122 ゜F) (except battery) |
Operating Humidity | 30 % to 85 %RH (no condensation) |
Finish | Resin, coating |
Dimensions | φ43.6 x 231.5 mm (φ1.72″ × 9.11″) |
Weight | 180 g (0.4 lb) (with battery) |
Accessory | Microphone holder W3/8″ (with stand adapter) …1, Screw driver …1, Storage case …1 |
